Equipment：We will introduce the manufacturing facility of Miyamoto engineering, that creating a high precision product.

Gear blank attachment/detachment work to human collaborative robot
－ YASKAWA Electric Corporation －
Automation by handling robot
－ NACHI-FUJIKOSHI CORP.　MZ07 －
Automation by handling robot
－ YASKAWA Electric Corporation　GP12 －
Handling robot carrying goods
－ YASKAWA Electric Corporation　MH12 －
Handling robot carrying goods
－ YASKAWA Electric Corporation　MH12 －
Hobbing M/C
Maker Type Spec Q'ty
HAMAI Co., LTD. 60SP m0.2～m2.0　MAXΦ160 5
(1 automated)
HAMAI Co., LTD. 120A ～m2.0　MAXΦ120 3
HAMAI Co., LTD. N60 ～m2.0　MAXΦ60
(with robot)		 2
HAMAI Co., LTD. N80 ～m3.0　MAXΦ80 1
KASHIFUJIWORKS LTD. KN series m1.0～m3.0　MAXΦ150
(4 is automated)		 11
KASHIFUJIWORKS LTD. KE series ～m6.0　MAXΦ250 3
KASHIFUJIWORKS LTD. KL-450 series ～m5.0　MAXΦ450 4
Total 29
Bevel gear tooth cutting M/C
Maker Type Spec Q'ty
TSUNASHIMA MACHIN TRADING Co., LTD. SBG-10B ～m2.5　Φ100 2
TSUNASHIMA MACHIN TRADING Co., LTD. SBG-10C ～m3.5　Φ160 8
Gleason Asia 175HC ～m5.0　Φ175 1
Gleason Asia Phoenix 100C ～m3.5　Φ10～Φ100 1
Total 12
Gear shaper
Maker Type Spec Q'ty
Karats Precision machinery, Ltd. GSM-12N ～m4.0
Outside tooth180
Inside tooth120		 1
MISTUBISHI HEAVY INDUSTRIES LTD. SE25A ～m6.0
Outside tooth250
Inside tooth PCD + 120mm
～Φ250		 3
MISTUBISHI HEAVY INDUSTRIES LTD. SE15A ～m4.0　外歯150　内歯PCD + 60mm
～Φ150		 1
Total 5
Gear grinding M/C
Maker Type Spec Q'ty
Gleason Asia 300TWG ～m8.0　～Φ300 1
Okamoto machine Tool Wrks Ltd. SHG360NCS ～m5.0　～Φ360 1
Nidec Corporation ZE26C ～m6.0　～Φ260 1
Nidec Corporation ZE40A n0.5～m8 1
KASHIFUJIWORKS LTD. KGH220   1
Total 5
Hobbing cutter polishing M/C
Maker Type Spec Q'ty
HAMAI Co., LTD. G-100 micron hobbing 2
KASHIFUJIWORKS LTD. KG <MAX Φ250・250L・depth ±35mm
groove 3～99		 2
MAKINO SEIKI CO.,LTD CNJ-5 Spillal・Zero-roll cuttter 1
Total 5
Broach M/C
Maker Type Spec Q'ty
SANJO MACHINE WORKS, LTD. VIJA-5100L 5 tons. Stroke 1000mm 1
SANJO MACHINE WORKS, LTD. VIJ-380G 3 tons. Stroke 800mm 1
Fujikoshi NBV-5-10A 5 tons. Stroke 1000mm 1
Total 3
NC. General-purpose M/C
Maker Type Spec Q'ty
Okuma Corporation LB300-M 8 inches 2
Okuma Corporation LB4000EX 15 inches 1
Okuma Corporation LB2000EXⅡ 8 inches 1
Okuma Corporation LB3000EXⅡ 8 inches 1
Okuma Corporation LB4000EXⅡ 15 inches 2
Okuma Corporation LB2500EXⅡ 8 inches 6
Okuma Corporation GENOSL250Ⅱ 8 inches 4
Takamatsu XL-100 6 inches 2
DMG MORI G100 4 inches 1
Total 20
Grinder M/C
Maker Type Spec Q'ty
Toyo Advanced Technologies Co., Ltd TVG-15C 9 inches
2 axis spec (Inner/Outer)		 1
Toyo Advanced Technologies Co., Ltd T-11JA 6 inches , 8 inches 2
Toyo Advanced Technologies Co., Ltd T-11JB 8 inches , 9 inches 2
Okamoto machine Tool Wrks Ltd. IGM15NCⅢ 8 inches 1
JTEKT CORPORATION GE-3P-25 387mm　Φ200mm 1
JTEKT CORPORATION GE4A-50Ⅱ 770mm　Φ320mm 1
JTEKT CORPORATION GE4-i 770mm　Φ320mm 1
JTEKT CORPORATION GE3Pi-25 250mm　Φ200mm 2
Okamoto machine Tool Wrks Ltd. PSG-63DX 600×300
(Table size)		 1
Okamoto machine Tool Wrks Ltd. PSG-84GX 840×400 1
KURODA PRECISION INDUSTRIES LTD. GS-64PFⅡ 600×400 1
SHIGIYA MACHINERY WORKS LTD. GAE-30B 500　～Φ300 1
Total 15
Machining Center
Maker Type Spec Q'ty
FANUC α-T14iA   4
Brother S7001N   2
Brother S700X2   1
Brother S700Xd1   1
Brother S700Xd2   2
Total 10
Radial ball M/C
Maker Type Spec Q'ty
TOMINAGA Co., Ltd RH-1225 From main spindle 1225mm 1
Total 1
Ion nitriding furnace
Maker Type Spec Q'ty
NDK, Incorporated JIN-3SC Furnace size 700×1000 2
Total 2
Welding robot
Maker Type Spec Q'ty
YASKAWA Electric Corporation SSA2000 Welding robot (MAG) 1
Total 1
Shot blast M/C
Maker Type Spec Q'ty
Nissin- Metal Co Ltd NL-2E Table Φ1400
Shot size Dia 0.6		 1
Total 1
Washing M/C
Maker Type Spec Q'ty
FINE MACHINE KATAOKA Co., LTD SPC-101-S Fine Machine 1
FINE MACHINE KATAOKA Co., LTD 06-4158 for small parts 1
Kobe Kousaku ACP-2001A Auto parts cleaner 1
Kobe Kousaku APC-1001 Auto parts cleaner 1
Total 4
3D measuring M/C
Maker Type Spec Q'ty
TOKYO SEIMITSU CO., LTD VF1000A 800×1000×600 1
TOKYO SEIMITSU CO., LTD SVA Fusion 900×1000×600 1
TOKYO SEIMITSU CO., LTD XYZAX MJU NEX 510×760×410 1
Total 3
Gear Inspection M/C
Maker Type Spec Q'ty
TOKYO TECHNICAL INSTRUMENTS INC., TTI-300E ～Φ300 1
TOKYO TECHNICAL INSTRUMENTS INC., TTI-450E ～Φ450 1
TOKYO TECHNICAL INSTRUMENTS INC., TTI-300H ～Φ300 1
Gleason Asia 300GMS ～Φ300 1
Total 4
Bevel gear meshing testing M/C
Maker Type Spec Q'ty
TSUNASHIMA MACHIN TRADING Co., LTD. UBT20 Bevel gear meshing test machine 5
TSUNASHIMA MACHIN TRADING Co., LTD. UBT-3 Bevel gear meshing test machine 9
TSUNASHIMA MACHIN TRADING Co., LTD. HPT-1 Bevel gear meshing test machine 1
Total 12
Meshing testing M/C
Maker Type Spec Q'ty
TOKYO TECHNICAL INSTRUMENTS INC., TF-40NC m0.2～2.0 2
Total 2
Surface roughness measuring M/C
Maker Type Spec Q'ty
TOKYO SEIMITSU CO., LTD SURCOM480A <Testing area>
Width 100㎜ Height 800μm		 1
Total 1
Hardness measuring M/C
Maker Type Spec Q'ty
Akashi Seisakusho ARD-A Rockwell 1
FUTURE-TECH CORP. FR-1E Rockwell 1
FUTURE-TECH CORP. FM-700e Micro Vickers 1
Total 3
Handling Robot
Maker Type Spec Q'ty
YASKAWA Electric Corporation MH12   2
YASKAWA Electric Corporation GP12   1
YASKAWA Electric Corporation HC20 Collaborative robot 1
Fujikoshi MZ07   2
Total 6
Shaft Straightening Machine
Maker Type Spec Q'ty
KOKUSAI CO., LTD. ASC-B15C-77 207mm~2000mm 1
Total 1
Contour and shape measuring instrument
Maker Type Spec Q'ty
TOKYO SEIMITSU CO., LTD SURFCOM NEX 030 DX-13 Contour, step, R angle, groove shape 1
計 1
